Utilizing a Furan Base No Bake, Phenol Free Sand System, Canada Alloy Castings can pour castings with a net delivery weight of 22,000 lbs. in a wide span of materials.
From carbon steel, to stainless steel, nickel alloys and aluminum bronze.
3 different process lines for different market needs in terms of size and service level:
Loop line: Casting weights from 25 lbs. to 4,000 lbs. Flask Size up to 50”X50
Floor Molding: Casting weights from 1,000 to 15,000 lbs. Flask size up to 12'X12'
Pit Molding: Casting weights from 10,000 to 17,000 lbs. Dimension: 20’X20’X16’
Melting is done by using our 5 Coreless Induction Furnaces. Combination of their individual capacity gives us the flexibility to respond to the specific requirements from our customers:
Furnaces: 2x 2,400 lbs. + 2x 3,400 lbs. + 1x 12,000 lbs.
